Day 36 Task: Managing Persistent Volumes in Your Deployment 💥

What are Persistent Volumes in k8s

In Kubernetes, a Persistent Volume (PV) is a piece of storage in the cluster that has been provisioned by an administrator. A Persistent Volume Claim (PVC) is a request for storage by a user. The PVC references the PV, and the PV is bound to a specific node. Read official documentation of Persistent Volumes.

Today's tasks:

Task 1:

Add a Persistent Volume to your Deployment todo app.

• Create a Persistent Volume using a file on your node.

• Create a Persistent Volume Claim that references the Persistent Volume.

• Update your deployment.yml file to include the Persistent Volume Claim. After Applying pv.yml pvc.yml your deployment file look like this

• Apply the updated deployment using the command: kubectl apply -f deployment.yml

• Verify that the Persistent Volume has been added to your Deployment by checking the status of the Pods and Persistent Volumes in your cluster. Use this commands kubectl get pods ,

kubectl get pv

⚠️ Don't forget: To apply changes or create files in your Kubernetes deployments, each file must be applied separately. ⚠️

Task 2:

Accessing data in the Persistent Volume,

• Connect to a Pod in your Deployment using command : `kubectl exec -it -- /bin/bash

`

• Verify that you can access the data stored in the Persistent Volume from within the Pod

Let’s do task 1

1. Create a pv. yml Persistent Volume using a file on your node.

    apiVersion: v1
    kind: PersistentVolume
    metadata:
      name: pv-app
    spec:
      capacity:
        storage: 1Gi
      accessModes:
        - ReadWriteOnce
      persistentVolumeReclaimPolicy: Retain
      storageClassName: manual
      hostPath:
        path: "/tmp/data"


   • apiVersion: v1: Specifies the API version used to create the object.

   • kind: PersistentVolume: Declares that this is a PersistentVolume (PV), which provides storage to pods.

   • metadata: name: pv-app: Names the PV as "pv-app".

   • spec:: Contains the specifications of the PV.

     • capacity: Defines the storage capacity (not shown fully here, but typically like storage: 1Gi).

     • accessModes: - ReadWriteOnce: Allows the volume to be mounted as read-write by a single node.

     • persistentVolumeReclaimPolicy: Retain: Prevents data deletion after the PV is released.

     • hostPath: path: "/tmp/data": Uses a directory from the host as storage.

This configuration sets up a local storage volume with 1GB capacity that can be used by one pod at a time and retains data after release.

2. Apply the Persistent Volume:

     kubectl apply -f pv.yml




3. Create a pvc.yml Persistent Volume Claim that references the Persistent Volume.

    apiVersion: v1
    kind: PersistentVolumeClaim
    metadata:
      name: pvc-app
      namespace: app-deployment
    spec:
      accessModes:
        - ReadWriteOnce
      resources:
        requests:
          storage: 1Gi
      storageClassName: manual


   • apiVersion: v1: Specifies the API version for the resource. v1 is the stable version for core Kubernetes resources like PV and PVC.

   • kind: PersistentVolume: Indicates that this is a PersistentVolume resource. A PersistentVolume is a piece of storage in the cluster that has been provisioned by an administrator.

   • metadata:

     • name: pvc-app: A name for this PersistentVolume. It’s used to identify the resource in the Kubernetes cluster.

   • spec:

     • accessModes:

       • - ReadWriteOnce: Specifies the access modes for the PersistentVolume. ReadWriteOnce means the volume can be mounted as read-write by a single node.

     • resources:

       • requests:

         • storage: 500Mi: Specifies the amount of storage requested. However, this field is used in PersistentVolumeClaim, not in PersistentVolume. For PersistentVolume, you should define the capacity field instead.

4. Apply the Persistent Volume Claim:

     kubectl apply -f pvc.yml




5. Create file name called storageclass.yml

    apiVersion: storage.k8s.io/v1
    kind: StorageClass
    metadata:
      name: manual
    provisioner: k8s.io/minikube-hostpath  # This is for local testing; adjust as needed for your environment


   provisioner: k8s.io/minikube-hostpath

   The provisioner field specifies which provisioner will be responsible for creating and managing Persistent Volumes (PVs).

   • k8s.io/minikube-hostpath is a provisioner used for Minikube, a Kubernetes environment designed for local testing. The hostPath provisioner stores data directly on the host node's filesystem, which is useful in development and testing scenarios but not recommended for production environments.

Use Case

This StorageClass is likely meant for local development and testing using Minikube. When a PersistentVolumeClaim (PVC) is created and uses this StorageClass, Kubernetes will use the hostPath provisioner to create storage directly on the local machine where Minikube is running.

In production environments, you would use different provisioners (like aws-ebs for AWS, gce-pd for GCP, etc.), depending on the cloud platform or storage solution you're using.

    kubectl apply -f storageclass.yml

6. Let’s update deployment file so create new update_deployment_3.0.yml file to include the Persistent Volume Claim.

    apiVersion: apps/v1
    kind: Deployment
    metadata:
      name: django-todo-deployment
      namespace: app-deployment
    spec:
      replicas: 2
      selector:
        matchLabels:
          app: django-todo
      template:
        metadata:
          labels:
            app: django-todo
        spec:
          containers:
          - name: django-todo
            image: anandraval12/django-todo-app:latest
            ports:
            - containerPort: 8000
            env:
            - name: DATABASE_URL
              valueFrom:
                secretKeyRef:
                  name: django-secret
                  key: database-url
            - name: SECRET_KEY
              valueFrom:
                secretKeyRef:
                  name: django-secret
                  key: secret-key
            volumeMounts:
            - name: todo-data
              mountPath: /app
          volumes:
          - name: todo-data
            persistentVolumeClaim:
              claimName: pvc-app


7. Apply the updated deployment:

     kubectl apply -f deployment.yml




8. Verify the Persistent Volume has been added to your Deployment.

     kubectl get pods -n <name-space name>
     kubectl get pv
     kubectl get pvc


Let’s do task 2

1. Get the Pod details:

     kubectl get pods




2. Connect to a Pod in your Deployment:

     kubectl exec -it <pod-name> -- /bin/bash




3. Verify that you can access the data stored in the Persistent Volume from within the Pod:

     cd /app/
     echo "Hello" > /app/test.txt
     ls


4. Delete the pod and verify the data persistence:

     kubectl delete pod <pod-name>
     kubectl get pods
     kubectl exec -it <new-pod-name> -- /bin/bash
     cd /app/
     ls
     cat test.txt


   Thankyou for reading !!!!!!
