Day 25 Task: 🚀Complete Jenkins CI/CD Project - Continued with Documentation 📄

Introduction

We completed till day 24 , we deployed project through cicd pipeline and learn aboout github hooks and many things so in this blog i made documentation about what we learned in jenkins

Steps for Jenkins CI/CD Project

Let's dive into the detailed documentation.

GitHub Setup

1. Create a GitHub Account: If you don't already have a GitHub account, you can create one by following the steps in Creating an account on GitHub.

2. Create a GitHub Repository: Once your account is set up, create a new repository by following the instructions in Create a GitHub Repository.

3. Set Up Git Configuration:

   • Open your terminal or command prompt.

   • Configure your Git username and email:

       git config --global user.name "Your Name"
       git config --global user.email "your-email@example.com"


4. Clone the Repository:

   • Copy the repository URL from GitHub.

   • Clone the repository to your local machine:

       git clone https://github.com/your-username/your-repository.git


5. Initialize Git Repository:

   • Navigate to your project directory:

       cd your-repository


   • Initialize the Git repository:

       git init


6. Add Files:

   • Add your project files to the repository:

       git add .


7. Commit Changes:

   • Commit your changes with a message:

       git commit -m "Initial commit"


8. Push Changes:

   • Push your changes to the remote repository:

       git push origin main


Docker and jenkins installation in ubuntu

1. Install Docker:

   • Update your package list:

       sudo apt-get update


   • Install Docker:

       sudo apt-get install -y docker.io


2. Install Docker Compose:

   • Download the Docker Compose binary:

       sudo curl -L "https://github.com/docker/compose/releases/download/1.29.2/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose


   • Apply executable permissions:

       sudo chmod +x /usr/local/bin/docker-compose


3. Install Java:

   • Install Java Development Kit (JDK):

       sudo apt-get install -y openjdk-11-jdk


4. Add Jenkins Repository Key:

   • Add the Jenkins repository key:

       wget -q -O - https://pkg.jenkins.io/debian/jenkins.io.key | sudo apt-key add -


5. Add Jenkins Repository:

   • Add the Jenkins repository to your sources list:

       sudo sh -c 'echo deb http://pkg.jenkins.io/debian-stable binary/ > /etc/apt/sources.list.d/jenkins.list'


6. Install Jenkins:

   • Update your package list and install Jenkins:

       sudo apt-get update
       sudo apt-get install -y jenkins


7. If you phase any problem then follow this link jenkins installation

8. Jenkins Service:

   • Start the Jenkins service:

       sudo systemctl start jenkins


Docker Setup

1. Add User to Docker Group:

   • Add your user to the Docker group:

       sudo usermod -aG docker $USER


2. Verify User Group Addition:

   • Verify that your user has been added to the Docker group:

       groups $USER


3. Fix Docker Permission Errors:

   • If you encounter permission errors, restart your machine or log out and log back in.

4. Create a Dockerfile:

   • Create a Dockerfile in your project directory. Example:

       FROM openjdk:11
       COPY . /app
       WORKDIR /app
       RUN ./mvnw package
       CMD ["java", "-jar", "target/your-app.jar"]


5. Build Docker Image:

   • Build your Docker image:

       docker build -t your-app .


6. List Docker Images:

   • List your Docker images to verify the build:

       docker images


7. Run Docker Container:

   • Run your Docker container:

       docker run -p 8080:8080 your-app


8. List Running Containers:

   • List running containers to verify your application is running:

       docker ps


9. Set Up Inbound Rules: Add specific ports to your instance for accessing your application via browser (refer to Setting up inbound rules).

Jenkins Setup

1. Access Jenkins: Visit <Your_Public_IP:8080> in your browser.

2. Unlock Jenkins: Use the admin password found in the location specified in the Jenkins setup page.

3. Set Up Jenkins: Follow the instructions in the Jenkins setup wizard to complete the setup.

4. Create a Freestyle Job: Create your first Jenkins job by referring to the Jenkins documentation on First Freestyle Job.

GitHub Webhook Integration

1. Create a Webhook in GitHub: Set up a webhook in your GitHub repository by following the instructions in How to create a Webhook.

2. Configure Webhook:

   • Payload URL: <Jenkins_URL:port/github-webhook/>

   • Select Events: Choose the events that should trigger the webhook.

3. Add Webhook: Click on the “Add webhook” button and refresh the page to confirm activation.

4. Integrate Webhook with Jenkins Job: Follow the steps in the Jenkins documentation to integrate the webhook with your Jenkins job.

5. Test Integration: Make changes to any file in your GitHub repo, commit the changes, and verify that Jenkins triggers the job automatically.

6. Access Application: Use <Your_Public_IP>:Port specified in your application to verify deployment.

Thankyou for reading !!!!!
