AWS Day 44: Implementing Auto Scaling for High Availability in AWS

As part of my KodeKloud 100 Days of Cloud journey, Day 44 focused on building a highly available web application using Amazon EC2, Auto Scaling Groups, and an Application Load Balancer (ALB).

The goal of this lab was to create an EC2-based web application that could automatically scale when traffic increased and continue serving requests through a load balancer.

For the application, I used Nginx as the web server. The EC2 instances were launched automatically using a launch template, while the Auto Scaling Group maintained the required number of instances.

Step 1: Create the EC2 Launch Template

I started by opening:

AWS Console → EC2 → Instances → Launch an instance

Instead of launching a standalone EC2 instance, the requirement was to create a reusable launch template.

The launch template was named:

datacenter-launch-template

A launch template allows us to define the configuration that should be used whenever the Auto Scaling Group launches a new EC2 instance.

This is useful because every instance created by the ASG can use the same:

• AMI

• Instance type

• Security group

• User Data

• Storage configuration

• Other launch parameters

Step 2: Select Amazon Linux 2

The task specifically required Amazon Linux 2.

I selected an Amazon Linux 2 AMI from the available AMI catalog.

The AMI provides the operating system environment that will be installed on every EC2 instance launched through the template.

For this task, Amazon Linux 2 was selected because the provided User Data uses amazon-linux-extras to install Nginx.

Step 3: Select the EC2 Instance Type

The required instance type was:

t2.micro

The t2.micro instance provides:

1 vCPU
1 GiB memory

It is appropriate for this lab because the workload is only a simple Nginx web server.

For production workloads, the instance type should be selected based on actual CPU, memory, network, and application requirements rather than simply using a small instance type.

Step 4: Configure the Security Group

The EC2 instances need to receive HTTP traffic from the Application Load Balancer.

I configured a security group with an inbound rule allowing:

Protocol : TCP
Port     : 80
Source   : HTTP traffic

The important requirement is that the web server must be reachable on port 80.

In a production environment, the preferred design would be more restrictive:

Internet
   |
   v
ALB Security Group
   |
   v
EC2 Security Group

The EC2 security group would allow port 80 only from the ALB security group instead of allowing HTTP from the entire internet.

For this lab, the required HTTP access was configured so that the ALB could successfully reach the Nginx instances.

Step 5: Configure User Data

One of the most useful parts of this lab was configuring EC2 User Data.

The objective was to automatically install and start Nginx whenever a new EC2 instance was launched.

I used:

#!/bin/bash

amazon-linux-extras install nginx1 -y
systemctl start nginx
systemctl enable nginx

This script performs three main operations.

Install Nginx

amazon-linux-extras install nginx1 -y

This installs Nginx on the Amazon Linux 2 instance.

Start Nginx

systemctl start nginx

This starts the Nginx service immediately.

Enable Nginx at boot

systemctl enable nginx

This ensures that Nginx automatically starts after the instance reboots.

This approach means that every new EC2 instance launched by the Auto Scaling Group can automatically become a web server without manually connecting to the instance.

Step 6: Create the Auto Scaling Group

After creating the launch template, I moved to:

EC2 → Auto Scaling Groups → Create Auto Scaling group

I created the Auto Scaling Group with the name:

datacenter-asg

The ASG uses:

datacenter-launch-template

as its instance configuration.

This means that any EC2 instance launched by the ASG uses the configuration defined in the launch template.

Step 7: Configure Group Capacity

The required capacity settings were:

Desired capacity : 1
Minimum capacity : 1
Maximum capacity : 2

So the initial configuration was:

datacenter-asg
       |
       v
Desired = 1
Min     = 1
Max     = 2

The desired capacity of 1 means the ASG initially launches one EC2 instance.

The minimum capacity of 1 ensures that the ASG does not scale down to zero instances.

The maximum capacity of 2 limits the number of instances that can be running as part of this lab.

Step 8: Configure CPU-Based Scaling

The task required the Auto Scaling Group to scale based on CPU utilization.

I selected:

Target tracking scaling policy

For the metric, I selected:

Average CPU utilization

The target value was:

50%

The scaling configuration was therefore:

Metric       : Average CPU utilization
Target       : 50%
Minimum      : 1
Desired      : 1
Maximum      : 2

The idea behind target tracking is simple.

If the average CPU utilization moves significantly above the target, the Auto Scaling Group can increase capacity.

If utilization falls and additional capacity is no longer required, the ASG can reduce capacity while respecting the minimum size.

This makes target tracking useful for workloads where CPU utilization is a reasonable indicator of application demand.

Step 9: Verify Nginx

Once the instance was running and the User Data script had completed, Nginx was available on port 80.

The browser test confirmed that the Nginx default page was being served.

The page displayed:

Welcome to nginx!

This confirmed that:
